See Fast Technologies designs, manufactures and sells smart high speed cameras. High speed: from 200 to 500 frames per second in full resolution, and more with ROI. Smart: an FPGA, Field Programmable Gate Array, embedded inside the camera, to authorize in real time, ultra high speed image processing ( at the camera frame rate ) The purpose of our products: To offer the possibility to achieve real time image processing during high speed shooting, in order to reduce the amount of data transmitted and to make the following possible: real time data transfer through standard interfaces like USB2 or Ethernet, achieve high speed feedback loop, long time recording on standard PC. Our engineers are specialized in: VHDL programming for FPGA, GUI (Graphical User Interface) design, design of electronic cards for images processing. With these skills, we propose, with specifications and based on our products, the following services: development and integration of custom algorithms, development of custom GUI, dedicated intelligent or smart high speed or high resolution camera design. www.seefastechnologies.com

Sensofar Metrology is a leading-edge technology company that has the highest quality standards within the field of surface metrology. Sensofar Metrology provides versatile, high-accuracy non-contact 3D surface profilers that are equipped with confocal, interferometric and focus variation techniques, all in a single sensor head. These systems are available in standard setups for fundamental research, for R&D and for standards & quality assurance laboratories, as well as complete and compact surface metrology sensors, ideally suited in terms of speed and flexibility for in-line production control. Sensofar Metrology offers technology that enables our customers to achieve real breakthroughs, particularly in the semiconductor, precision optics, data storage, display devices, thick and thin film and material testing technology fields. The Sensofar Group headquarters is located close to Barcelona, the technological heart of Spain. The Group is represented in over 20 countries through a global network partners and has its own offices in Asia and the United States. http://www.sensofar.com

SensUp designs and manufactures OEM: Original Equipment Manufacturer optical systems based on lasers technology. Products and applications include laser rangefinder for target’s distance measurement and laser scanning: LIDAR for obstacle detection. www.sensup-tech.com
c:\users\carloslee\appdata\local\microsoft\windows\temporary internet files\content.outlook\hn2nwnqc\seren_logo-high resolution (2).jpg
Seren Photonics is a spin-out from the University of Sheffield. It has commercialised technology developed by Prof Tao Wang of the Electronic and Electrical Engineering Department and uses nano engineered structures to enhance the properties of III-Nitride materials. Seren Photonics' focus is on development and manufacture of semi-polar and non-polar Gallium Nitride (GaN) templates designed to enhance the performance of GaN LED's, lasers, VCSELs and power switches. www.serenphotonics.com
sgc equipment AWAITING DESCRIPTION www.sgcequipment.com

Sicoya a spin off from TU Berlin, is developing silicon photonics (SiPh) based photonic integrated circuits (PICs) for optical data center interconnects using a fabless business model. The founding team raised 4.9 M€ of nonrepayable public funds for R&D in the last 8 years. Sicoya aims to enter the market with a 4x25 Gbit/s sealed and packaged transceiver chip for intra data center connections with link distances up to 2 km. Sicoya designs, packages and sells silicon photonic based Application Specific Photonic Integrated Circuits (ASPICs). Our technology enables the production of highly integrated optical transceivers at very low manufacturing costs. Extremely small integrated form factors lead to practical and cost efficient scaling roadmaps for Terabit per second data rates. www.sicoya.de

Sinochip designs, manufactures and sells high end transmitter and receiver components for multiple applications in the fiber optic Telecom market. The company’s products are targeted at the high growth parts of the market like Data centers, GPON and Metro. The company has many years’ experience in the InP market; in technology, products as well as in sales.

SMART Photonics, located in Eindhoven, The Netherlands, is a Pure Play Foundry offering production services for Indium Phosphide (InP) based photonic components.

We use our extensive photonics knowledge, many years of experience in III-V production and dedicated equipment to create and produce the photonic designs of our customers.

We offer the complete creation process from first Epitaxial growth, high resolution lithography, re-growth, wafer processing, metallization, polishing of wafers up to the coating of the chip facets. We help our customers with either a single process step or the full production process whether they are in the proof of concept phase or require volume production.

Fast prototyping of PICs in InP on MPW-runs. SMART Photonics has further developed its generic integration technology for integration of InP based photonic components. For this new technology, free access to the SMART Photonics design manual is offered to customers to design their own PICs. Designs can be easily, and cost effectively, tested in the SMART Photonics MPW-runs which are offered on a quarterly basis. www.smartphotonics.nl


c:\users\carloslee\appdata\local\microsoft\windows\temporary internet files\content.outlook\hn2nwnqc\logo.png
SMT Partner relies on the 30 years industrial experience in the field of optical components and subsystems of its founder, to provide services to industry and investors. The services include:

  • Technology expertise in the field of optical component and subsystems

  • Services to build R&D projects and R&D partnership

  • Services for R&D funding

  • Services for industrial strategy, including industrial partnership or contract manufacturing

  • Market analysis and product roadmap

  • Marketing and Technology support to investors for M&A

  • Services to industry to build business plans and contribute to define the company strategy


c:\users\carloslee\appdata\local\microsoft\windows\temporary internet files\content.outlook\hn2nwnqc\new logo.jpg
SM:V is a sales and marketing consultancy specialising in Photonics. With nearly 20 years’ experience, we provide practical, hands-on sales and marketing expertise. Whether clients require marketing communications support, brand expertise or market research support, using SM:V clients remove all the associated costs of hiring full-time marketing employees. This gives clients the flexibility to reduce overheads and tailor our services according to their needs. We work across a wide range of markets from instrumentation and displays through to micro-optics and holography. www.sm-v.co.uk

Sofradir is the European leader in high performance imaging related to Defence, Space and Civil systems. Our company masters and proposes a wide range of technologies such as : QWIP, InSb, InGaAs and MCT. The MCT technology permits Sofradir to position itself as the world leader of infrared detectors using this technology. As a worldwide company, Sofradir, whose shareholders are Thales and Sagem (Safran group), brings to its customers its experience and expertise in the development of leading-edge technologies. www.sofradir.com

Soitec generates and manufactures revolutionary semiconductor materials for electronic and energy industries. Soitec is developing and manufacturing SOI: Silicon-on-Insulator materials, advanced substrates for microelectronic and CPV power plant for high irradiance countries. Soitec is an international company, with R&D and industrial manufacturing activities in France, Germany, Singapore, and the United States with headquarters in Bernin, near Grenoble, France. www.soitec.com
Funded Research Projects Experience .

Soitec is and has been involved into many national and European projects, both as coordinator and participant, in projects such as:



  • Eureka Catrene : SOI450: 450mm SOI substrates and technologies

  • Eureka Catrene : Dynamic ULP: Smaller, faster, better CMOS technology

  • Eureka Euripides : THOR: Striking technologies for Power

  • FP7 : NACIR: hybrid solar project


******AWAITING DESCRIPTION******* www.specim.fi


https://www.opfocus.net/arcv/2011/06/05/072221spi_web_logo.jpg
SPI Lasers is a leading designer and manufacturer of premium Fiber Lasers for welding, cutting, marking, drilling, micro-machining and additive manufacturing. Operations can be carried out faster and more accurately with an SPI Laser for better reliability, less waste and improved productivity. The product portfolio covers countless application process areas across a wide range of industries including automotive, electronics and the medical device sectors. SPI Lasers is a wholly owned subsidiary of the TRUMPF group and sells its products globally, and has its major business operations, including research and development, and manufacturing in the UK, USA and Asia, as well as worldwide sales and customer support. www.spilasers.com
Funded Research Projects Experience .

  • LIFT: Leadership in Fibre Laser Technology

  • Acted as a subcontractor to various EU programmes

  • Involved with numerous collaborative programmes funded by the UK Technology Strategy Board


c:\users\carlos lee\appdata\local\microsoft\windows\temporary internet files\content.outlook\wy12bxzl\sqs_logo_blue_small.jpg
SQS Vlaknova Optika, established in 1994, is a manufacturer of fiber optic and optoelectronic components. SQS production is based primarily on its own R&D focused on new products development, existing products innovations and on development of special customer solutions. The company has gradually shifted to technology leaders in respective sectors also through several transfers of advanced technologies. The transfers underpin long-term cooperation with foreign partners e.g. in high-reliable optical components manufactured by the fusion technology mainly for applications in undersea telecommunications, and in the field of optoelectronic components production for applications in multimedia optical networks installed in high-class automobiles. SQS optoelectronic production is based on standard semiconductor manufacturing processes for packaging components in the form of chips on the wafer level. Rich experience in semiconductor manufacturing has become the base for the latest SQS activities in the production of LED light sources (light engines) in the form of hybrid integrated circuits. www.sqs-fiber.cz

Spectra-Physics Rankweil (former High Q Laser GmbH) specializes in the development and production of both medical and industrial ultrafast laser systems. Its high-quality, maintenance-free products serve in a variety of applications such as micro-machining and ophthalmology as reliable and dependable work horses. With several thousand laser systems in the field, Spectra-Physics Rankweil is one of the leading ultrafast laser manufacturers when it comes to 24/7 applications. www.spectra-physics.com

SUPERLUM Diodes develops and manufactures low coherent light sources based on semiconductor superluminescent diodes (SLD) and driving electronics in 650-1620 nm spectral range, as well as semiconductor optical amplifiers (SOA) and tunable swept light sources (SS) in 750-1100 nm spectral range. SUPERLUM products are used by over 250 companies worldwide in various applications: Optical Coherence Tomography (OCT), Fiber-Optic Sensing and Metrology, Non-Destructive Testing (NDT), Fiber-Optic Gyros, Speckle Free Illumination and others. Our R&D group can design and manufacture complete opto-electronic systems for your application. www.superlumdiodes.com
suss micro-optics
SUSS MicroOptics is a manufacturer for high-quality refractive and diffractive micro-optics in 200mm: 8’’ wafer technology, based in Neuchâtel, Switzerland. SUSS MicroOptics meets highest demands as required for applications in photolithography, optical networking, laser, medical and metrology. In 2013 SUSS MicroOptics moved to a new cleanroom facility: class 100/1000. SUSS MicroOptics is ISO9001:2008 qualified and SGS attested. www.suss.ch
Funded Research Projects Experience .

  • ACTMOST: Access to Micro-Optics Expertise, Services and Technologies

  • JEMSIP_3D: Joint Equipment & Materials for System-in-Package and 3D Integration

  • NEMO: Network of Excellence for Micro-Optics

  • WALORI: WAfer Level Optic solution foR compact CMOS Imager

  • SEAL: Semiconductor Equipment Assessment Leveraging Innovation



Swiss-FO’s role is to provide to our partners quality telecom infrastructure deployment services and advice and resources to benefit from the innovative technological advances while promoting the best local actor. http://www.swiss-fo.com/
c:\epic\pictures and videos\members logos\swissphotonics.jpg
SWISSPHOTONICS serves as a network for a common vision and growth of the photonics industry in Switzerland. It is the declared goal of SWISSPHOTONICS to promote the competitiveness of its members through the support of the innovation forces. www.swissphotonics.net

  • SWISSPHOTONICS serves the full field of photonics, including material processing with a laser beam, photonic manufacturing, optical input/output: imaging and photonic life science, optical communication, photovoltaics and lighting.

  • SWISSPHOTONICS serves companies, research facilities, and universities in the field of photonics from basic science over applied science, technology development, manufacturing and selling of photonic components and applications.

  • SWISSPHOTONICS supports networking within Switzerland and establishes contacts within Europe, especially to the European technology platform Photonics21.



SYLEX, a mid-size company founded in 1995, is a world-class original design manufacturer of high quality optical interconnect solutions. Our superb engineering and design capabilities, strong quality control systems, and substantial manufacturing capacity allows us to deliver both high-volume and custom-tailored solutions extremely rapidly as clients or the market require. For telecom and datacom markets SYLEX specializes in designing and manufacturing MTP harnesses, PRIZM LightTurn and MXC assemblies and high density DURALINO fanout trunks for enterprise, carrier, and specialty applications like shuffles for supercomputing interconnection solutions. SYLEX offers tailor made automated monitoring system solutions based on modernized FBG technology. These systems, which have been repeatedly verified by many projects around the world, are used to monitor the structural health and geotechnical safety of infrastructure projects. Our sensors utilize the principle of Fiber Bragg Gratings manufactured by either Draw Tower Technology (DTG) or Femto-Second writing technology (FS), thus providing the systems with unique advantages compared to the conventional electrical solutions (or even compared to standard FBG based monitoring systems). SYLEX sensing solutions are suitable for strain, temperature, displacement, vibration and deformation measurements within the Mining industry, Civil Engineering, Geo-technical markets or any other SHM and monitoring purposes. http://www.sylex.sk/
c:\users\alffi\appdata\local\microsoft\windows\inetcache\content.word\logo hd.png
Sy&Se is a start up from the Haute Ecole Arc Ingénierie (HE-Arc) specialized in joining technologies of micro and macro systems. In many manufacturing processes, assembling is an essential step and it contributes to obtaining a high-quality and efficient finished product. Since mastering the technology and the manufacturing costs of each step is imperative for companies, the SY&SE propose, building up on a major scientific discovery, a new ICB (Impulse Current Bonding) binding process, which combines cost-effective and robust assembly of glasses on various metals, glasses on silicon, silicon on fused silica, sapphire on silicon and glasses, and also stacks of these materials. High quality of the bond interface obtained with the innovative ICB technique is particularly well suited for photonic systems based on integration of optical compounds with cleanness, precision and stability (covalent bonds). Related to this aspect, hermeticity between adjacent surfaces or for device encapsulation required for efficient performance and moisture prevention is a serious advantage. Other assembly configurations with more common optical waveguide materials such as for example InP, GaAs, or GaN on glasses are also possible (by the use of intermediate evaporated thin layers). www.syandse.ch
c:\epic\pictures and videos\members logos\optoelectronics research centre.tif
Tampere University of Technology: TUT operates in the form of a foundation and has a long-standing tradition of collaboration with other research institutions and business life. The Optoelectronics Research Centre: ORC at Tampere University of Technology, founded in 2000, is the research center in optoelectronics and photonics in Finland. High-quality fundamental and applied research is carried out in five research groups: semiconductor technology, ultrafast and intense optics, nanophotonics, few cycle optics and surface science. Having played a seminal role in the formation of several high-profile spin-off companies, ORC has close ties with the industry and provides services for business such as processing and characterization of nanophotonic components. www.tut.fi/orc
Funded Research Projects Experience .

  • RAMPLAS: Silicon-based, integrated Optical RAM enabling High-Speed Applications in Computing and Communications

  • LIFT: Leadership In Fiber Technology



TE Connectivity is a $12 billion global technology leader. Our connectivity and sensor solutions are essential in today's increasingly connected world. We collaborate with engineers to transform their concepts into creations - redefining what's possible using intelligent, efficient and high-performing TE products and solutions proven in harsh environments. Our 72,000 people, including 7,000 engineers, partner with customers in over 150 countries across a wide range of industries. We believe EVERY CONNECTION COUNTS. www.te.com

The tec5 group develops and manufactures high-quality, state-of-the-art products for detector array based optical spectroscopy and photometry for a wide range of applications. The company`s portfolio includes products ranging from OEM Components, like Operating Electronics, via Embedded Systems up to complete UV-VIS-NIR and Raman Spectrometers. In addition, we work out custom-tailored product solutions in close cooperation with our customers. tec5 was established in 1993. With a network of distribution partners, we work together with customers around the globe. www.tec5.com
http://www.technospark.ru/images/logo_eng.png
The TECHNOSPARK Nanotech Center was established in 2012 under the auspices of the consortium of scientific and research institutes, continuing centers of shared use, scientific and educational centers, and educational institutions of the town of Troitsk: New Moscow. The implementation in Troitsk was conditioned by the high concentration in the town of large research centers in the sphere of laser technology, superhard and new carbon materials, spectroscopy and nuclear physics. Now, science-based experimental and small series productions of nanotech products exist and develop using the auspices and in the experimental and production facilities of scientific and research institutes. Technospark has its own brand new facilities for startups development and production and is a heart of the most fast-growing technopark in Russia. www.technospark.ru
c:\users\carlos lee\appdata\local\microsoft\windows\temporary internet files\content.outlook\wy12bxzl\technobis-group (2).png
Technobis group is a developer and supplier of high-tech instruments and modules for OEM companies around the world. Technobis tft-fos is specialized in the development and supply of fibre optic sensing systems and applications. All developments are spectrometry and or interferometry based. Starting with free-space optics 17 years ago, nowadays all new developments are based on integrated photonics. Application Specific Photonic Integrated Circuits: ASPICs allow custom and highly dedicated system designs for a versatile range of improved performance requirements. Technobis ipps is a specialized solution provider for ASPIC packaging by supplying dedicated and mid-range volume packaging services. As ASPIC packaging requires complex dedication, our key values are thermal: and mechanical stability, high performance, low-noise, low power consumption, easy but versatile integration, reliable and repeatable quality. Technobis mechatronics is specialized in carrying out complete product development projects, going from an idea to a successful turnkey product, prototype or series product. www.technobis.nl

Funded Research Projects Experience .

• SARISTU: Smart Intelligent Aircraft Structures www.saristu.eu



• TAPAS: Thermoplastic Affordable Primary Aircraft Structure Consortium www.tapasproject.nl

Technology Scotland is the leading cluster organisation focusing on the development of the Key Enabling Technology (KET) sectors in Scotland. We provide an independent voice for the KEY communities in Scotland and promote our member’s diverse range of technologies for the benefit of the industry and wider economy. With these values at our core, we work to bring together industry, academia and government in technology clusters that develop new products and services utilising KETs. We deliver a range of services to help members increase their global competitiveness and act as a conduit to and from the Technology Advisory Group within Scottish Enterprise. www.technologyscotland.scot
